Capable of 1500 Horsepower!
- 82mm Compressor Wheel Inducer
- 80mm Turbine Wheel Exducer
- Ball Bearing
- Integrated Backing Plate
- Speed Sensor Provision
- Weight is 25 lbs
- Stainless Turbine Housing Options:
- T4 Inlet V-Band Outlet 0.96 A/R
- T4 Inlet V-Band Outlet 1.24 A/R
- V-Band In & Out 0.96 A/R
- V-Band In & Out 1.24 A/R
Modernized iron bearing housing with an integral backplate to resist backplate deflection under heavy loads!
Stronger Shaft Weld Joint for Durability
Including improved compressor wheel and turbine wheel aerodynamics.
8 More Reasons You Will Love HPT Turbos...
These turbochargers have been developed for increased reliability and improved performance resulting in a longer life to the customer!
1. Large diameter dual turbine piston ring for oil and gas seal
2. Stronger shaft wheel weld joint for durability
3. Improved compressor wheel and turbine wheel aerodynamics!
4. Updated turbine housing to maximize the inlet and outflow
5. Compressor cover is modernized to efficiently process the increased flow!
6. Stainless steel v-band in/out housings
7. Modernized iron bearing housing with an integral backplate to resist backplate deflection under heavy loads!
8. A warranty program that will make any driver smile.
